ZHUO YUE
ZY005
| PERFORMANCE | |
| Lumen Output(lm) | 5705lm |
| Power Consumption | 60W |
| Efficacy(lm/W) | 95lm/w |
| CCT(K) | 4000K(Topic) |
| CRI(Ra) | >75 |
| Lumen Maintenance (LM-80) | L70(9K): 256,000 hours |
| @ 77 °F (25 °C) | L70 calculated: 36,000+hours |
| Input Voltage | 85-265 VAC, 50/60 Hz |
| | 127V-370 VAC, option available |
| Power Factor | 0.90 minimum |
| LED Source | 192pcs EPISTAR SMD2835 LED |
| Wiring Options | .Two ½-inch conduit entries for direct wiring |
| | . Per LM-79-08 test methods. |
| | . Nominal CCT, as defined by ANSI C78.377-2008. |
| PHYSICAL | |
| Dimensions (L x W x H cm) | 150x90x70cm |
| Weight | 6 pcs/carton (34 kg) |
| Mounting Options | .Aircraft cable suspension |
| | .Rigid mount |
| Material | AL Housing frosted PC coverall board |
| Clips | Stainless Steel |
| | |
| SENSING AND CONTROL(option) | |
| Onboard Intelligence | .Microwave occupancy sensor |
| | .Censored On/Off and dimming |
| | .10%-100% |
| Dimming Levels | .Discrete levels via PIR Control switches |
| | |
| EMERGENCY(option) | |
| Battery | 18650 Li-ion |
| Rechargeable Times | Up to 500 times |
| Back Up Time | 2-3 Hours |
| PERFORMANCE | |
| Lumen Output(lm) | 5705lm |
| Power Consumption | 60W |
| Efficacy(lm/W) | 95lm/w |
| CCT(K) | 4000K(Topic) |
| CRI(Ra) | >75 |
| Lumen Maintenance (LM-80) | L70(9K): 256,000 hours |
| @ 77 °F (25 °C) | L70 calculated: 36,000+hours |
| Input Voltage | 85-265 VAC, 50/60 Hz |
| | 127V-370 VAC, option available |
| Power Factor | 0.90 minimum |
| LED Source | 192pcs EPISTAR SMD2835 LED |
| Wiring Options | .Two ½-inch conduit entries for direct wiring |
| | . Per LM-79-08 test methods. |
| | . Nominal CCT, as defined by ANSI C78.377-2008. |
| PHYSICAL | |
| Dimensions (L x W x H cm) | 150x90x70cm |
| Weight | 6 pcs/carton (34 kg) |
| Mounting Options | .Aircraft cable suspension |
| | .Rigid mount |
| Material | AL Housing frosted PC coverall board |
| Clips | Stainless Steel |
| | |
| SENSING AND CONTROL(option) | |
| Onboard Intelligence | .Microwave occupancy sensor |
| | .Censored On/Off and dimming |
| | .10%-100% |
| Dimming Levels | .Discrete levels via PIR Control switches |
| | |
| EMERGENCY(option) | |
| Battery | 18650 Li-ion |
| Rechargeable Times | Up to 500 times |
| Back Up Time | 2-3 Hours |
